Parts of the Printer
Phaser® 8560/8860 Printer
1-3
Right Side View
Rear View
1. Maintenance kit
2. Waste tray
3. Power cord connection
4. Power switch
5. USB connection
6. Configuration card
7. Ethernet 10/100 Base-Tx connection
1. Optional hard drive
2. Two RAM slots
8860
p
-045
1
2
3
4
5
6
7
1
8860p-046
2
