LLooaaddiinngg LLaabbeellss iinn TTrraayy 11
1. To remove the tray from the printer, pull out the tray until it stops. Lift the front of the tray
slightly, then pull it out.
2. Adjust the paper length and width guides.
3. Load the label sheets in the tray, face up.
Note: Do not load paper above the maximum fill line. Overfilling can cause paper jams.
4. Slide the tray back into the printer.
5. Push the tray in all the way.
6. If the Tray Mode is set to Fully Adjustable, the printer prompts you to set the label sheet size,
type and color.
a. If the paper size, type and color are correct, touch OK.
Xerox
®
VersaLink
®
C600 Color Printer
User Guide
123
Paper and Media
