CClleeaarriinngg JJaammss iinn tthhee OOffffiiccee FFiinniisshheerr LLXX

CClleeaarriinngg PPaappeerr JJaammss UUnnddeerr tthhee TToopp CCoovveerr ooff tthhee OOffffiiccee FFiinniisshheerr LLXX

1. Pull up the lever on the top cover.

2. To open the top cover, rotate it to the left.

3. Remove the jammed paper.

Note: If the paper is torn, remove all torn pieces from the finisher.

4. Close the top cover of the finisher.

250

Xerox

VersaLink

C70XX Color Multifunction Printer

User Guide

Troubleshooting
