Xerox WorkCentre 6025

Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-32
Item Part Name Part Number
1. FEED ASSY MSI (with 2-7) 059K 88840
2 CAM MSI R --
3 ROLL CORE MSI --
4 ROLL ASSY FEED 059K 78701
5 HOLDER FEED --
6 SHAFT FEED --
7 CAM MSI L --
8 HOLDER BTM R --
9 HOLDER BTM L --
10 HOLDER ASSY SEPARATOR (with 22-24) 019K 16020
11 SPRING SEPARATOR 809E 91661
12 FOLLOWER R 008E 97513
13 FOLLOWER L 008E 97503
14 HOLDER ARM L 019E 89680
15 SPRING NF 809E 91681
16 ACTUATOR NO PAPER 120E 35361
17 COVER NO PAPER 019E 89721
18 SENSOR PHOTO (NO PAPER SENSOR) 930W 00123
19 ARM MSI R 019E 89690
20 HARNESS ASSY RKN SNS (J12-J120,J121,J122) --
21 PLATE BOTTOM TIE --
22 CLUTCH ASSY FRICTION --
23 ROLL ASSY SEPARATOR --
24 HOLDER SEPARATOR --
25 ARM BOTTOM IN L --
26 ARM BOTTOM IN R --
27 PLATE ASSY SEPARATOR --
28 SLIDE STOPPER --
29 SPRING STOPPER --
30 SPRING ACT NO PAPER MAIN --
31 SPRING ACT NO PAPER SUB --
32 ACTUATOR NO PAPER SUB --
33 PLATE ARM L --
34 PLATE ARM R --
