Xilinx Mimas Spartan 6 FPGA User Manual

Mimas is an easy to use FPGA Development board featuring Xilinx Spartan-6 FPGA. Mimas is specially designed for experimenting and learning system design with
development board features Xilinx XC6SLX9 TQG144 FPGA with maximum 70 user IOs. The USB 2.0 interface provides fast and easy conguration download to the
don’t need a programmer or special down loader cable to download the bit stream to the board.
Applications
Product Prototype Development
Home Networking
Signal Processing
Wired and Wireless Communications
Educational tool for schools and universities
Board features
FPGA: Spartan-6 XC6SLX9 in TQG144 package
Flash memory: 16 Mb SPI ash memory (M25P16)
100MHz CMOS oscillator
USB 2.0 interface for On-board ash programming
FPGA conguration via JTAG and USB
8 LEDs and four switches for user dened purposes
70 IOs for user dened purposes
On-board voltage regulators for single power rail operation
2. How to Use Mimas – Spartan 6 FPGA Development Board
2.1. Components/Tools Required
Along with the module, you may need the items in the list below for easy and fast installation.
1. USB A to Mini B cable.
2. DC Power supply (Optional).
2.2. Connection Diagram

