Xilinx SP701 - Additional Resources; Block Diagram

The following table lists the models for this board. See the SP701 evaluaon board product page
for details.
Table 2: Models of SP701 Boards
Kit Description
EK-S7-SP701-G Xilinx Spartan-7 FPGA SP701 Evaluation Kit
EK-S7-SP701-G-J Xilinx Spartan-7 FPGA SP701 Evaluation Kit, Japan Specific
Additional Resources
See Appendix D: Addional Resources and Legal Noces for references to documents, les, and
resources relevant to the SP701 evaluaon board.
Block Diagram
The following gure shows the various components of the SP701 Evaluaon Board.
Figure 1: SP701 Evaluation Board Block Diagram
