ZC702 and ZVIK Getting Started Guide www.xilinx.com 35
UG926 (v3.0.1) February 12, 2013
Running the Qt-Based GUI Application Demonstration
3. Wait for the ZC702 board to be configured and booted with Linux. The XILINX ZYNQ
banner appears on the display monitor after approximately two minutes as shown in
Figure 3-5.
4. The Qt-based video demonstration application starts. The GUI application shows up at
the bottom of the screen (see Figure 3-6).
X-Ref Target - Fi gure 3-5
Figure 3-5: Zynq Linux Command Prompt
UG926_c3_05_111012
