Xinje DP3F Series User Manual

16
P1-08
0x0108
Position Ki
0~65535
500
P1-09
0x0109
Back EMF
1~300
50
P1-10
0x010A
Weak magnetic
coefficient
1~100
20
P1-11
0x010B
Inductance
1~10000
1000
P1-12
0x010C
Startup delay
1~10
1
P1-13
0x010D
In place delay
0~100
3
P1-14
0x010E
In place error
0~100
4
Group P2: IO configuration parameters
Parameter
Address
Function
Range
Default
Note
P2-00
0x0200
Motor enable
0~1
0
0: not enable 1: enable
P2-01
0x0201
Z phase output
0~1
0
0: high level 1: low level
P2-02
0x0202
Alarm output
0~1
0
0: high level 1: low level
P2-03
0x0203
Brake output
0~1
0
0: high level 1: low level
P2-04
0x0204
In place output
0~1
0
0: high level 1: low level
P2-05
0x0205
Alarm clear
0~1
0
0: high level 1: low level
Group P3: protection function parameters
Parameter
Address
Function
Range
Default
Note
P3-00
0x0300
Tracking error limit
1~65535
4000 (1 turn)
P3-01
0x0301
Fault detection
selection
0~65535
255
P3-02
0x0302
Under voltage alarm
threshold
0~20
0
When the default value is 0,
the alarm is shielded
Group P4: motor parameters
Parameter
Address
Function
Range
Default
Note
P4-00
0x0400
peak current
305: 1~30
705: 1~70
808: 1~84
305: 25
705: 60
808: 74
0.1A
P4-01
0x0401
Encoder
resolution
200~20000
4000
Quadruple frequency,
modification not supported
P4-02
0x0402
Operation
direction
0~1
0
0: counter clockwise; 1: clockwise
Group P5: self-operation parameters
Parameter
Address
Function
Range
Default
Note
P5-00
0x0500
Self-operation
mode
0~1
0
0: infinite pulse 1: set pulse
P5-01
0x0501
Pulse high
byte
0~65535
0
P5-02
0x0502
Pulse low
byte
0~65535
4000
Pulse number = pulse high byte×65535+pulse
low byte
P5-03
0x0503
Speed
0~2000
200
rpm
P5-04
0x0504
Acceleration
1~2000
200
rpm/s
