Xinje DP3F Series User Manual

17
speed
P5-05
0x0505
Direction
0~1
0
0: counter clockwise; 1: clockwise
P5-06
0x0506
shuttle run
0~1
0
0: single direction 1: double direction
P5-07
0x0507
Repeat
0~2
0
0: not repeat 1: repeat times 2: always repeat
P5-08
0x0508
Repeat times
0~65535
0
P5-09
0x0509
Repetition
interval
0~65535
1000
ms
P5-10
0x050A
Startup speed
0~2000
200
rpm
P5-11
0x050B
Stop speed
0~2000
200
rpm
P5-12
0x050C
Operation
status
0~3
0
0: idle 1: run 2: deceleration stop 3: emergency
stop
Group P7: communication parameters
Parameter
Address
Function
Range
Default
Note
P7-00
0x0700
Driver station
no.
1~100
1
P7-01.0
0x0701.0~1
Baud rate
03：2400
04：4800
05：9600
06：19200
07：38400
08：57600
09：115200
0A：192000
0B：256000
0C：288000
06
Default 19200bps, 1 stop bit, even
parity
P7-01.2
0x0701.2
Stop bit
0: 2 bits
2: 1 bit
2
P7-01.3
0x0701.3
Parity bit
0: no parity
1: odd
parity
2: even
parity
2
P7-02
0x0702
Communication
protocol
0~1
1
1: Modbus, 0: others
P7-03
0x0703
Reserved
1~65535
1
P7-04
0x0704
Reserved
1~65535
1
Group U0
Parameter
Address
Content
Note
U0-00
0x1000
Set speed
rpm
U0-01
0x1001
Feedback speed
rpm
U0-02
0x1002
Encoder quantity
0~15 bits
Encoder pulse
U0-03
0x1003
16~31 bits
U0-04
0x1004
32~47 bits
U0-05
0x1005
48~62 bits, 63: direction bit
U0-06
0x1006
Feedback pulse numbers
0~15 bits
Command pulse
