Xinje DP3F Series User Manual

18
Parameter
Address
Content
Note
U0-07
0x1007
16~31 bits
U0-08
0x1008
32~47 bits
U0-09
0x1009
48~62 bits, 63: direction bit
U0-10
0x100A
Pulse numbers
0~15 bits
Command pulse
U0-11
0x100B
16~31 bits
U0-12
0x100C
32~47 bits
U0-13
0x100D
48~62 bits, 63: direction bit
U0-14
0x100E
Position offset
0~15 bits
Command pulse
U0-15
0x100F
16~31 bits
U0-16
0x1010
Single turn encoder
counting value
0~15 bits
Encoder pulse
U0-17
0x1011
16~31 bits
U0-18
0x1012
Single turn pulse
counting value
0~15 bits
Command pulse
U0-19
0x1013
16~31 bits
U0-20
0x1014
Pulse turns
0~15 bits
U0-21
0x1015
16~31 bits
U0-22
0x1016
Encoder turns
0~15 bits
U0-23
0x1017
16~31 bits
U0-24
0x1018
Feedback electric angle
U0-25
0x1019
Set electric angle
U0-26
0x101A
A phase feedback current
mA
U0-27
0x101B
B phase feedback current
mA
U0-28
0x101C
Reference feedback current
mA
U0-29
0x101D
A phase set current
mA
U0-30
0x101E
B phase set current
mA
U0-31
0x101F
Reference set current
mA
U0-32
0x1020
Bus voltage
V
Group U1 monitor parameters
Parameter
Address
Content
Note
U1-00
0x1100
Present alarm code
U1-01
0x1101
Phase A current when alarm occurs
U1-02
0x1102
Phase B current when alarm occurs
U1-03
0x1103
Reference current when alarm occurs
U1-04
0x1104
Bus voltage when alarm occurs
U1-05
0x1105
Position offset when alarm occurs
U1-06
0x1106
Speed when alarm occurs
U1-07
0x1107
The time when alarm occurs
0~15 bits
U1-08
0x1108
The time when alarm occurs
16~31 bits
U1-09
0x1109
Error numbers for this time operation
U1-10
0x110A
Latest 2nd alarm code
U1-11
0x110B
Latest 3rd alarm code
U1-12
0x110C
Latest 4th alarm code
U1-13
0x110D
Latest 5th alarm code
U1-14
0x110E
Latest 6th alarm code
