Xinje DS2-22P3-AS User Manual

70
Voltage level
380V
Motor type
MS-
110ST-
130ST-
130ST-
180ST-
M04030
M05030
M06025
M10015
M10030
M1901
5
M2001
5
□□-41P
2
□□-41P
5
□□-41P5
□□-43P0
Motor code
0131
0132
0142
0144
1148
0156
1052
Rated power (KW)
1.2
1.5
1.5
1.5
3.0
3.0
3.0
Rated current (A)
3.0
3.9
3.7
3.5
6.4
7.5
7.8
Rated speed (rpm)
3000
3000
2500
1500
3000
1500
1500
Max speed（rpm）
3500
3500
3000
2000
3500
2000
2000
Rated torque（N·m）
4
5
6
10
10
19
20
Peak torque（N·m）
12
15
18
25
25
47
50
Back EMF constat
（V/krpm）
89
90
110
177
88.3
158
138
Torque coefficient
（N·m/A）
1.33
1.11
1.62
2.86
1.56
2.53
2.56
Rotor inertia（Kg·m
2
）
0.54×10
-3
0.63×10
-3
1.26×10
-
3
1.94×10
-
3
1.125×10
-3
3.8×10
-
3
2.8×10
-3
Winding resistor（Ω）
3.30
2.28
3.50
4.37
0.46
1.15
0.67
Winding inductance
（mH）
8.78
7.40
10.75
15.00
1.52
6.40
2.68
Electrical time
constant（ms）
2.66
3.25
3.07
3.46
3.33
5.57
4.00
Weight（Kg）
5.5
6.1
8.9
11.5
11.4
20.5
17.1
Encoder ppr（PPR）
2500
Pole pairs
4
Motor insulation level
Class B（130℃）
Protection level
IP65
Ambie
nt
Temperatur
e
－20℃～＋50℃
Humidity
Relative humidity < 90% (no condensation)
 60, 80 and 90 series servomotors winding connector
Motor Winding
connector
Winding Name
U
V
W
PE
Connector
1
3
2
4
 60, 80 and 90 series servo motor encoder connector
Signal
5V
0V
B+
Z-
U+
Z+
U-
A+
V+
W+
V-
A-
B-
W-
PE
Connector
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
 110, 130, 180 series servo motor winding connector
Motor Winding
connector
Winding Name
U
V
W
PE
Connector
2
3
4
1
