Xinje DS3 Series

37
Note:
The servo motor bus function needs to be equipped with the bus module, which is inserted
into the driver CN1 port for the purpose of extending the bus function. Please note that the
transfer module should not be hot-pluggable. It is recommended to use the profibus standard
cable to achieve the best communication reliability.
 Pulse wiring diagram
Command
Choice
Meaning
P-input
signal
D-input
signal
P0-10
xxx□
0
CW, CCW double
pulse mode
CW
CCW
1
AB phase mode
A phase
B phase
2
Pulse + direction
mode
Pulse
Direction
Collector open circuit (24V) input positive signal: P+24V/D+24V
Differential mode (5V) input positive signal: P+5V/D+5V
Note: DS3E, DS3L series servo cannot support CW, CCW double pulse mode.
