Xinje DS3 Series Manual

76
electronic gear ratio
65535
15
Pulse frequency
corresponding to speed
mode rated speed
*100
Hz
1000
0~
10000
○
7
16
Speed command pulse
filter time
0.01
ms
100
0~
10000
○
7
18
Encoder feedback pulse
per circle×1
1
2500
0~9999
○
All the
modes
19
Encoder feedback pulse
per circle×10000
1000
0
0
0~
9999
○
All the
modes
20
Encoder pulse frequency
division (numerator)
-
1
0~
65535
○
All the
modes
21
Encoder pulse frequency
division (denomination)
-
1
0~
65535
○
All the
modes
23
Pulse offset limit
*256
com
mand
unit
50000
0~
65535
√
6
24
Discharge resistor type
0: internal
1: external
-
0
0~1
○
All the
modes
25
Discharge resistor power
W
-
0~
65535
√
All the
modes
26
Discharge resistor value
Ω
-
0~
500
√
All the
modes
27
Servo OFF stop mode
0: inertia running stop,
keep the inertia running
-
0
0, 2
○
All the
modes
