Xinje XC Series Hardware Manual

Appendix 1 special soft device list
Appendix 1-3．ID List of the Expansions
Take the first expansion module as the example:
Channel
AD
signal
DA
signal
PID
Output
value
PID
run/stop bit
Set value
PID parameter: Kp, Ki, Kd,
control range Diff、Death
range death
XC-E8AD
0CH ID100 - ID108 Y100 QD100
1CH ID101 - ID109 Y101 QD101
2CH ID102 - ID110 Y102 QD102
3CH ID103 - ID111 Y103 QD103
4CH ID104 - ID112 Y104 QD104
5CH ID105 - ID113 Y105 QD105
6CH ID106 - ID114 Y106 QD106
7CH ID107 - ID115 Y107 QD107
Kp-----QD108
Ki------QD109
Kd-----QD110
Diff----QD111
Death--QD112
XC-E4AD2DA
0CH ID100 - ID104 Y100 QD102
1CH ID101 - ID105 Y101 QD103
2CH ID102 - ID106 Y102 QD104
3CH ID103 - ID107 Y103 QD105
0CH - QD100 - - -
1CH - QD101 - - -
Kp-----QD106
Ki------QD107
Kd-----QD108
Diff----QD109
Death--QD110
XC-E4DA
CH Nr. Exp. 1 Exp. 2 Exp. 3 Exp. 4 Exp. 5 Exp. 6 Exp. 7
0CH QD100 QD200 QD300 QD400 QD500 QD600 QD700
1CH QD101 QD201 QD301 QD401 QD501 QD601 QD701
2CH QD102 QD202 QD302 QD402 QD502 QD602 QD702
3CH QD103 QD203 QD303 QD403 QD503 QD603 QD703
XC-E2DA
CH Nr. Exp. 1 Exp. 2 Exp. 3 Exp. 4 Exp. 5 Exp. 6 Exp. 7
0CH QD100 QD200 QD300 QD400 QD500 QD600 QD700
1CH QD101 QD201 QD301 QD401 QD501 QD601 QD701
XC-E6PT-P/ XC-E6TC-P
D8612 Read the expansion’s times
D8613 Read the expansion’s error ……
D8614 write the expansion’s error times
D8615 write the expansion’s error ……
Expansion 4
…… …… …… ……
…… …… …… ……
D8624 Read the expansion’s times
D8625 Read the expansion’s error ……
D8626 write the expansion’s error times
D8627 write the expansion’s error ……
Expansion 7
