Xinje XC Series Hardware Manual

8 expansion devices
0V
24V
C1
C0
AI0 VI1 C2 AI2 VI3
AI3C3VI2A11VI0
VO0 VO1
AO1C1AO0C0
CH NAME SIGNAL CH NAME SIGNAL
AI0 Current analogue input AI1 Current analogue input
VI0 Voltage analogue input VI1 Voltage analogue input
CH0
C0 COM of CH0
CH1
C1 COM of CH1
AI2 Current analogue input AI3 Current analogue input
VI2 Voltage analogue input VI3 Voltage analogue input
CH2
C2 COM of CH2
CH3
C3 COM of CH3
AO0 Current analogue output AO1 C
urrent analogue output
VO0 Voltage analogue output VO1 Voltage analogue output
CH0
C0 COM of CH0
CH1
C1 COM of CH1
24V +24V power supply
-
0V COM of power supply
8-3-3．XC-E4AD
Terminal Arrangement 3
Brief Introduction 1
l 4CH analogue input: voltage and current input selectable; Voltage input range is 0～5V、
0～10V selectable, current input range is 0～20mA、4～20mA selectable;
l 14 bits high precision analogue input;
l As the special module, 7pcs XC-E4AD can be connected to one XC series PLC main unit;
l XC-E4AD module support PID auto tune function;
