Xinje XC Series - XC-E4 AD Module Details

8 expansion devices
AO1
Current analogue output
VO1
Voltage analogue output
CH1
C1
COM of CH1
24V
+24V power supply
-
0V
COM of power supply
8-3-6．XC-E6PT-P
1※ : If no signal input, the value is 3500;
2※ : According to the actual requirements, connect with Pt100 resistors
Items Content
Analogue Input Signal Pt100 resistor
T
emperature testing range
-100℃～350℃
Digital Output range -1000～3500
, 16bits with sign, binary
Control precision ±0.5℃
Distinguish Ratio 0.1℃
Integral Precision 0.8% (Relate to the max value)
Convert Speed 20ms/CH
Power Supply DC24V±10%，50mA
Brief Introduction 1
Specification 2
l Pt resistor input, the scale is Pt100
l 6CH input, 6CH output, 2 groups PID parameters (3CH/group)
l 1mA constant output, doesn’t effected by the environment;
l The distinguish precision is 0.1℃
l As the special module, 7pcs XC-E6PT-
P can be connected to one XC series PLC main unit;
