Xinje XC Series Hardware Manual

5 input specifications and wiring methods
5-1．Input Specification
Input signal’s voltage DC24V±10%
Input signal’s current 7mA/DC24V
Input ON current Up to 4.5mA
Input OFF current Low than 1.5mA
Input response time About 10ms
Input signal’s format Contact input or NPN open collector transistor
Circuit insulation Photo-electricity coupling insulation
Input action’s display LED light when input ON
Input signal’s voltage DC24V±10%
Input signal’s current 7mA/DC24V
Input ON current Up to 4.5mA
Input OFF current Low than 1.5mA
Input response time About 10ms
Input signal’s format Contact input or NPN open collector transistor
Circuit insulation Photo-electricity coupling insulation
Input action’s display LED light when input ON
Basic Units
1
Expansion Modules 2
