Xinje XC Series Hardware Manual

Appendix 1 special soft device list
Temperature difference δ
(unit: 0.1℃)
(sample temperature+ Temperature difference δ)/10=display temperature value. Then
temperature display value can equal or close to the real temperature value. This
parameter has sign (negative or positive). Unit is 0.1℃, the default value is 0.
The set temperature
value(unit: 0.1℃)
Control system’s target temperature value. The range is 0～1000℃, the precision is
0.1℃.
Temperature control cycle
(unit: 0.1s)
Control cycle’s range is 0.5s～200s, the minimum precision is 0.1s. the write value is
the real temperature control cycle multiply 10. i.e. 0.5s control cycle should write 5,
200s control cycle should write 2000.
Adjust environment
temperature value
(unit: 0.1℃)
If users think the environment temperature is different with the display temperature, he
can write in the known temperature value. At the moment of value written in, calculate
the temperature difference δ and save.
Calculate the temperature difference value δ=adjust environment temperature value－
sample temperature value. Unit: 0.1℃.
E.g.: under heat balance status, user test the environmental temperature as 60.0℃ with
mercurial thermometer, the display temperature is 55.0℃ (correspond sample
temperature is 550), temperature difference δ=0. at this time, users write this
parameters with 600，temperature difference δ is re-calculated to be 50 (5℃), then the
display temperature = (sample temperature＋temperature difference δ）/10 =60℃。
**Note: when users write the adjust temperature value, make sure that the temperature
is same with the environment temperature value. This value is very important, once
it’s wrong, temperature difference δ will be wrong, then effect the display temperature
Auto tune output value
The output when auto tune, use % as the unit, 100 represents 100% of full scale
output. 80 represents 80% of full scale output.
XC-E3AD4PT2DA
CH Nr.
AD
signal
PID output
value
PID run/stop bit Set value
PID parameters: Kp、Ki、
Kd、control range Diff、
death range Death
0CH ID100 ID107 Y100 QD102
1CH ID101 ID108 Y101 QD103
2CH ID102 ID109 Y102 QD104
CH Nr.
PT
signal
PID output
value
PID run/stop bit Set value
3CH ID103 ID110 Y103 QD105
4CH ID104 ID111 Y104 QD106
5CH ID105 ID112 Y105 QD107
6CH ID106 ID113 Y106 QD108
Kp------- QD109
Ki------- QD110
Kd------- QD111
Diff------ QD112
Death---- QD113
CH Nr.
DA
signal
- - -
0CH QD100 - - -
-
