Xinje XC Series Hardware Manual

2 The Specifications and Parameters of CPU
Items
Specifications
Program Executing Form Loop scan form
Program Form Instruction、Ladder
Dispose Speed 0.5 us
Power Off Retentive Use FlashROM
User's program space
※
1
128K
Total I/O 14 16 24 32 48 60
Input
8
X0~X7
8
X0~X7
14
X0~X15
18
X0~X21
28
X0~X33
36
X0~X43
I/O points
※
2
Output
6
Y0~Y5
8
Y0~Y7
10
Y0~Y11
14
Y0~Y15
20
Y0~Y23
24
Y0~Y27
Internal Coils (X)
※
3
X0~X777 (512)
Internal Coils (Y)
※
4
Y0~Y777 (512)
M0~M2999
【M3000~M7999】
※
5
Internal Coils (M)
8768
points
For Special Use
※
6
M8000~M8767
Flow (S)
1024
points
S0~S511
【S512~S1023】
T0~T99：100ms not accumulate
T100~T199：100ms accumulate
T200~T299：10ms not accumulate
T300~T399：10ms accumulate
T400~T499：1ms not accumulate
T500~T599：1ms accumulate
points
640
points
T600~T639：1ms precise time
Timer
Spec.
100mS timer: set time 0.1~3276.7sec.
10mS timer: set time 0.01~327.67sec.
1mS timer: set time 0.001~32.767sec.
C0~C299: 16 bits sequential counter
C300~C598: 32 bits sequential/inverse counter
C600~C619: single phase high speed counter
C620~C629: dual-phase high speed counter
points
640
points
C630~C639：AB phase high speed counter
Counter (C)
Spec.
16 bits counter: set value K0~32,767
32 bits counter: set value -2147483648~＋2147483647
D0~D999
【D4000~D4999】
※
5
Data Register (D)
2612
Words
For Special Use
※
6
D8000~D8511
2 XC2 Series

Xinje XC Series Specifications

General

Brand	Xinje
Model	XC Series
Category	Controller
Language	English
