Xinje XC Series Hardware Manual

2 The Specifications and Parameters of CPU
Input
14
X0~X015
18
X0~X021
28
X0~X33
※
2
Output
10
Y0~Y011
14
Y0~Y015
20
Y0~Y23
Internal Coils (X)
※
3
X0~X1037 (Total 544)
Internal Coils (Y)
※
4
Y0~Y1037 (Total 544)
M0~M2999
【M3000~M7999】
※
5
Internal Coils (M) 8768 points
For Special Use
※
6
M8000~M8768
Flow (S) 1024 points
S0~S511
【S512~S1023】
T0~T99：100ms not accumulate
T100~T199：100ms accumulate
T200~T299：10ms not accumulate
T300~T399：10ms accumulate
T400~T499：1ms not accumulate
T500~T599：1ms accumulate
points 640 points
T600~T639：1ms precise time
Timer
Spec.
100mS timer: set time 0.1~3276.7sec.
10mS timer: set time 0.01~327.67sec.
1mS timer: set time 0.001~32.767sec.
C0~C299: 16 bits sequential counter
C300~C598: 32 bits sequential/inverse counter
C600~C619: single phase high speed counter
C620~C629: dual-phase high speed counter
points 640 points
C630~C639：AB phase high speed counter
Counter (C)
Spec.
16 bits counter: set value K0~32,767
32 bits counter: set value -2147483648~＋2147483647
D0~D2999
【D4000~D4999】
※
5
Data Register (D) 5024 words
For Special Use
※
6
D8000~D9023
FD0~FD63
For Special Use
※
6
FD8000~FD8349
524 words
For Special Use
※
6
FD8890~FD8999
Expand the internal
registers (ED)
※
7
36864 words ED0~ED36863
High Speed Dispose
Ability
High speed counter, pulse output, external interruption
Password Protection 6 bits ASCII
Self-diagnose Function Power on self-check、monitor the timer、grammar check
※1：the user's program space: refer to the maximum program space when download secretly.
