6 output specification and wiring methods
Interior power Below DC5~30V
Circuit insulation Optical coupling insulation
Action denote Indicate lamp LED
Restance load 0.8A
Induce load 12W/DC24V
Max
load
Lamp load 1.5W/DC24V
Open circuit’s leak
current
-
Mini load DC5V 2mA
OFF→ON Below 0.2ms Response
time
ON→OFF Below 0.2ms
Normal Transistor
Output
2
