8 expansion devices
l Input Specification
Input Items Content
Input signal’s voltage DC24V±10%
Input signal’s current 7mA/DC24V
Input ON current Up to 4.5mA
Input OFF current Low than 1.5mA
Input response time About 10ms
Input signal’s format Contact input or NPN open collector transistor
Circuit insulation Photo-electricity coupling insulation
Input action’s display LED light when input ON
l Relay output
Input Items Content
Internal power Below AC250V、DC30V
Circuit insulation Mechanism insulation
Action denote LED indicate lamp
3A 3A
80VA 80VA
Max load
100W 100W
Open circuit’s leak current -
DC5V 2mA 10ms Mini load
Response time
10ms 10ms
l Transistor Output
Input Items Content
Internal power Below DC5~30V
Circuit insulation Optical coupling insulation
Action denote Indicate lamp LED
0.8A 0.8A Max load
12W/DC24V 12W/DC24V
Module Specification 2
Power Supply Specification
DC24V (32 I/O expansion is AC220V)
