Xinje XC Series Hardware Manual

8 expansion devices
8-3-8．XC-E3AD4PT2DA
Items
Analogue Current Input
(AD)
Temperature Input
(PT)
Analogue Voltage
Output (DA)
Analogue input DC0～20mA、4～20mA PT100 -
Temperature
testing range
- -100~350℃ -
Max input range DC0～40mA - -
Analogue output
range
- -
DC0~5V、
0~10V(external load
resistor 2KΩ~1MΩ)
Digital input
range
- - 10 bits Binary (0~1023)
Digital Output
Range
14 bits Binary (0~16383) -1000~3500 -
Distinguish Ratio
1/16383(14Bit): The
converted data is stored
in PLC in Hex. (14Bit)
0.1℃
1/1023(10Bit): The
converted data is stored
in PLC in Hex. (10Bit)
PID Output Value 0~K4095 -
Integral Precision 0.8% ±0.5℃ 0.8%
Convert Speed 20ms/CH 3ms/CH
Power Supply DC24V±10%，100mA
Brief Introduction 1
Specification 2
l 3CH 14bits current input、4CH PT100 temperature input and 2CH 10bits voltage output
l 3CH AD is current (0~20mA、4~20mA) selectable; 2Ch DA is voltage (0~5V、0~10V)
selectable, choose via the software;
l Pt resistor input, the scale is PT100
l 3CH A/D and 4CH PT input are equipped with PID auto tune function;
l As the special module, 7pcs XC-E3AD4PT2DA can be connected to one XC series PLC main
unit;
