Xinje XC1 Series User Manual

Appendix 2 instructions list
Appendix 2-1．Basic Instructions List
Mnemonic
Function
LD
Initial logical operation contact type NO (normally open)
LDI
Initial logical operation contact type NC (normally closed)
OUT
Final logic operation type coil drive
AND
Serial connection of NO
ANI
Serial connection of NC
OR
Parallel connection of NO
ORI
Parallel connection of NC
LDP
Rising edge pulse
LDF
Falling edge pulse
ANDP
Serial connection of rising edge pulse
ANDF
Serial connection of falling edge pulse
ORP
Parallel connection of rising edge pulse
ORF
Parallel connection of falling edge pulse
LDD
Read the point
LDDI
Read NC
ANDD
Read the point and serial connection
ANDDI
Read NC and serial connection
ORD
Read the point and parallel connection
ORDI
Read NC and parallel connection
OUTD
Output the point
ORB
Parallel connection of parallel multiply parallel circuit
ANB
Serial connection of parallel multiply parallel circuit
MCS
New bus line start
MCR
Bus line return
ALT
Alternate state
PLS
Rising edge pulse
PLF
Falling edge pulse
SET
Set a bit device permanently on
RST
Reset a bit device permanently off
OUT
Output counter coil
RST
Output reset, and current data reset to zero
END
I/O process and return to step0
GROUP
Instruction block fold start
GROUPE
Instruction block fold end
TMR
Time
