Wireless Access Point
Installing the Wireless AP 77
AP Management Interfaces
User Interfaces
With zero-touch setup provided by XMS and Mobilize, your Xirrus network is
ready for use a few minutes after deployment. We recommend that you use the
XMS for ongoing monitoring and fine-tuning of the network.
To check the configuration of individual APs locally, AP settings may be viewed
or configured through the Command Line Interface (CLI) using SSH, or on a
browser with the Web Management Interface (WMI). You may use the CLI via the
serial management port (console—on all APs except the XR-500/600/1000 Series
and some XR-2000 models) or any of the Gigabit Ethernet ports. You can use the
WMI via any of the AP’s Ethernet ports.
Figure 33. Network Interface Ports—XR-520 (left); XR-1000 Series (right)
Figure 34. Network Interface Ports—XR-600 Series
Figure 35. Network Interfaces—XR-2000 Series (left); XR-2005/2006 (right)
Gigabit2 (gig2)
Gigabit1/PoE+ (gig1)
Gigabit1 PoE /Gigabit1 PoE+
Gigabit2
CONSOLE
