XO FLEX Installation instructions Installation
26
Figure 27 Cables shall be placed between the outer cylinder and bridge arm post
Connect cables and hoses to plugs and fittings, see Figure 28 to Figure 32.
Figure 28 Connecting return air hose: (1) transparent light blue 6 mm return air hose from instrument bridge
connected to the oil collector at the unit front
