3. REAR SUSPENSION
ECCENTRIC BUSHINGS HAVE TWO DIFFERENT OFFSETS FROM THE CENTER.
Middle position = 0.5° or 0.375mm from center.
Outer position = 1° or 0.75mm from center.
The XRAY rear alu lower suspension holders provide great range of adjustment for the rear suspension. Using different combinations of eccentric bushings, fine adjustment of rear anti-squat, rear toe-in, rear
roll center, and rear track-width can be obtained. For more information about the influence of rear anti-squat, rear toe-in, rear roll center and rear track width on car handling, please refer to HUDY Set-up Book
(#209100).
The tables describe the amounts of adjustment using the center and outside positions of the eccentric bushings.
The middle position eccentric bushings allow for finer adjustment increments.
The track-width is directly influenced by the size of
the wheels and tires used.
ANTI-SQUAT ROLL CENTER TRACK-WIDTH TOE-IN
RR RR RR RRRF RF
RF
RF(°) (mm) (mm)
(°)
=2°
=3°
=1°
=3°
=2°
=4°
=1°
=2°
=0°
=1°
=2°
=0°
=2°
=1°
=-1°
=2°
=3°
=1°
=
+
1.5mm
=
0mm
=
-
1.5mm
=
+
0.75mm
=
0mm
=
-
0.75mm
➊
Marked “L”
Marked “R”
2mm
from rear arm
2mm
from rear arm
Arm Reamer 3.0mm
(HUDY #107633)
If the suspension arm does not move freely
use a HUDY Arm Reamer to size the holes
of the arms.
➊
➋
➌
➌
➍
➍
RR 1°
RF
903312
SFH M3x12
From Rear Arm
SHIM 3x6.5x2
REAR BLOCK
IMPORTANT
DETAIL
Check for free movement
DETAIL
Composite eccentric bushings
0.5°
1°
INITIAL SETTING
Composite eccentric bushings
0.5°
1°
INITIAL SETTING
SHORT REAR SUSPENSION ARM
#363112-H RIGHT HARD INCLUDED
#363122-H LEFT HARD INCLUDED
#363112-G RIGHT GRAPHITE OPTION
#363122-G LEFT GRAPHITE OPTION
LONG REAR SUSPENSION ARM
#363113-H RIGHT HARD OPTION
#363123-H LEFT HARD OPTION
#363113-G RIGHT GRAPHITE OPTION
#363123-G LEFT GRAPHITE OPTION
For SHORT arms do not use INNER
positions.
For LONG arms do not use OUTER
positions.
0.5°
1°
0.5°
1°
For SHORT arms use only OUTER
positions.
For LONG arms use only INNER
positions.
#363314
ALU LOWER SUSP.
HOLDER 3° REAR-FRONT
NARROW - 7075 T6
1-DOT
3°
