Xray XB4 User Manual

37
902316
SH M3x16
902312
SH M3x12
ALU NUTS M3
#296530-B BLUE OPTION
#296530-K BLACK OPTION
#296530-O ORANGE OPTION
#960031 SILVER INCLUDED
8. FINAL ASSEMBLY
28mm
902308
SH M3x8
960030
N M3
960030
N M3
➊
➍
➌➌
NOTE
ORIENTATION
NOTE
ORIENTATION
➊
➌
➋
➍
NOTE
ORIENTATION
➋
Servo screw
(NOT INCLUDED)
Servo
(NOT INCLUDED)
902306
SH M3x6
3x6mm
3x6mm
3x8mm
HUDY ALU SERVO HORNS
#293497 23T
#293498 24T
#293499 25T
HUDY CLAMP ALU SERVO HORNS
#293404 23T
#293405 24T
#293406 25T
For more in-corner steering and better steering
response, aluminum servo horns may be used.
INITIAL POSITION
INITIAL POSITION
INITIAL POSITION
INITIAL POSITION
USE APPROPRIATE SERVO ARM:
(23T) (24T) (25T)
K H F
961032
SHIM S 3.2
THREAD
THREAD
6mm THREAD
6mm THREAD
SERVO LINK
Adjust servo link to fit your servo.
Install the pivot balls with Professional
Multi Tool (HUDY #183011)
DETAIL
DETAIL
DETAIL
DETAIL

Xray XB4 Specifications

General

Drive	4WD
Suspension	Independent
Type	Buggy
Battery Type	LiPo
Differential	Gear
Motor Type	Brushless
Class	Off-Road
Radio System	2.4 GHz
Scale	1:10
