41
960240
N M4
8. FINAL ASSEMBLY
903308
SFH M3x8
Rear wheel (WIDE)
Front wheel (NARROW)
FINAL ASSEMBLY VIEW
OPTIONAL ALU WING SHIM
#293561 SILVER OPTION
#293561-O ORANGE OPTION
#369912-M
4WD FRONT WHEEL AERODISK WITH
12MM HEX IFMAR - WHITE - M (2)
#329913-M
2WD/4WD REAR WHEEL AERODISK
12MM HEX IFMAR - WHITE - M (2
