XS Instruments COND 70 Vio User Manual

14
Rev. 1 24/01/2020
EN
• Instrument transportation
The instrument is always supplied with the appropriate carrying case. Use the original case only, to transport
the instrument. If you need to buy it again, contact your local distributor.
The interior of the case is shaped to be able to house the instrument and the sensors still connected.
• Key functions
Button
Pression
Function
Short
Press to turn the device on or off.
Short
In measure mode, press to scroll through the different parameters:
• pH 70 Vio: pH  mV  ORP
• COND 70 Vio: Cond  TDS  Sal
• PC 70 Vio: pH  mV  ORP  Cond  TDS  Sal
Short
• In calibration, setup and memory recall mode, press to return to measure
mode.
• In measure mode, press to start the calibration.
Short
In measure mode, press to enter the setup.
In the setup menus, press to select the desired program and / or value.
During calibration, press to confirm the value.
Short
In the setup and subset menus press to scroll
In the setup submenus, press to change the value
In memory recall mode, press to scroll through the saved values.
In MTC and customer calibration mode, press to change the value.
: In measure mode, press to save the data (manual Data Logger) or start
and end the recording (Automatic Data Logger).
: In measure mode, press to recall the saved data.
Long-press
(3s)
In measure mode, keep one of the two keys pressed to change the temperature
in MTC mode (manual compensation, without probe). When the value starts to
flash, the user can change the temperature value by entering the correct one and
confirming with .
IMPORTANT:
• When the Sleep mode is active (by default after two minutes of inactivity of the instrument) press
any key to reactivate the brightness of the display.
• Only at this point do the keys regain their function.
