Xtant 2200ix - OWNERS INSTALLATION LOG

OWNER’S INSTALLATION LOG
Upon installation of your mobile audio sound system, your
Authorized Xtant Select Dealer will complete this log. Keep
this owners manual with your vehicle as a reference for all
amplifier settings.
OWNERS NAME:
VEHICLE:
MAKE/MODEL: YEAR:
XTANT AMPLIFIER SERIAL #
CROSSOVER SETTINGS: JUMPER SETTINGS:
SIP HIGH PASS FQ AMPLIFIER: (circle setting)
VALUE CODE: ALL HIGH LOW BAND PASS
SIP LOW PASS FQ RCA OUTPUTS
VALUE CODE: ALL HIGH LOW
INPUT SENSITIVITY JUMPER OUTPUT GAIN ADJUSTMENT
–20 dB
–10 dB
0 dB
+10 dB
+20 dB (
DRAW ARROW POSITION)
NOISE GATE ADJUSTMENT ACCESSORY MODULES
SWITCH: ON OFF CM 24X YES NO
THRESHOLD POSITION PQM-1 YES NO
PQM-1 CHIP FREQUENCY
(DRAW ARROW POSITION)
XTANT SELECT DEALER:
PHONE:
INSTALLATION SPECIALIST:
DATE INSTALLED:
LEFT
RIGHT
