Xtant 2200ix SPECIFICATIONS
Frequency Response 5 Hz to 50 kHz +/– 1 dB
Number of Channels 2
Watts per Channel @ 4Ω 2 x 100
Watts per Channel @ 2Ω 2 x 200
Bridged Mono @ 4Ω 1 x 400
Recommended Load (Ω)2Ω Stereo / > 4Ω Bridged
Distortion (THD) < .04%
MEASURED: 20 HZTO20 KHZ AT RATED POWER, ALL CHANNELS DRIVEN 4Ω
Signal to Noise Ratio > 100 dB
MEASURED: A-WEIGHTED IN 20 KHZ NOISE BANDWIDTH @ 1 VOLT SENSITIVITY
Damping Factor > 200 @ 100 Hz with 4Ω load
Input Sensitivity 100 mV to 8.5 V RMS Unbalanced Source
100 mV to 17 V RMS Balanced Source
Input to Line Output Gain 0 dB +/– 20 dB, Selectable in 10 dB steps
On-Board Crossover 18 dB per Octave “Butterworth”
Module Port(s) 1 - Accessory Port
Power Supply Fully Regulated, “Transitional”
Operational Voltage 11 to 15 Volts
Fusing 50 Amp
Warranty Limited 4 year Parts and Labor
SEE PAGE 11 OF THIS MANUAL FOR COMPLETE DETAILS
6
