11
STEP 5 REAR HANDLEBAR
1. Attach the rear handlebar (76) to the lower back support tube (74), tighten using 2 curved washers (13)
and 2 Allen screws (81).
STEP 6 CONSOLE
2 Allen Screws (#81)
2 Curved washers (#13)
