Xterra FS3.5 - Assembly Hardware Checklist; Hardware Step 1 Components; Hardware Step 2 Components

FS3.5 Elliptical
3
#80. 5/16” x 15mm
Button Head Socket
Bolt (6 pcs)
FS3.5 Assembly Pack Checklist
Hardware Step 1
#112. 3/8” x 23 x 1.5T
Curved Washer
(2 pcs)
#104-1. Ø8.7 x 20 x 1.5T
Flat Washer
(2 pcs)
Hardware Step 2
#96. 3/8”
Cap Nut
(2 pcs)
#82. M5 x 15mm
Phillips Head
Screw (4 pcs)
#77. 3/8” x 3”
Carriage Bolt
(2 pcs)
#80-1. 5/16 ” x 15mm
Button Head Socket Bolt
(2 pcs)
#111. 5/16” x 1.5T
Split Washer (6 pcs)
#113. 5/16” x 23 x 1.5T
Curved Washer (2 pcs)
#84. M5 x 10mm
Phillips Head Screw
(4 pcs)
#105. 5/16” x 23 x 1.5T
Flat Washer (4 pcs)
