Xterra FS5.25e User Manual

Xterra FS5.25e Elliptical
5
ASSEMBLY PACK CHECK LIST
Step 1
#112 - 3/8" x 1-1/2"
Hex Head Bolt (2pcs)
#152 - 3/8" x 19mm
Flat Washer (2pcs)
#149 - 5/16" x 23mm
Flat Washer (4pcs)
#124 - M5 x 10mm
Phillips Head Screw (4pcs)
#158 - 3/8"
Split Washer (1pc)
#110 - 5/16" x 2-1/4"
Hex Head Bolt (4pcs)
#111 - 3/8" x 3/4"
Hex Head Bolt (2pcs)
#157 - 5/16"
Split Washer (4pcs)
#159 - 5/16"
Star Washer (4pcs)
#139 - 3/8"
Nyloc Nut (2pcs)
#113 - 3/8" x 2-1/4"
Hex Head Bolt (1pc)
#156 - 3/8" x 23mm
Curved Washer (2pcs)
