Xterra FS5.25e User Manual

Xterra FS5.25e Elliptical
6
#149 - 5/16" x 23mm
Flat Washer (2pcs)
#107 - 5/16" x 15mm
Hex Head Bolt (2pcs)
#155 – 17mm
Wave Washer (4pcs)
#128 - 3.5mm x 12mm
Sheet Metal Screw (6pcs)
Step 3
Step 4
#128 - 3.5mm x 12mm
Sheet Metal Screw (8 pcs)
#125 - M5 x 15mm
Phillips Head Screw (18pcs)
#109 - 5/16 x 1-1/4”
Hex Head Bolt (2pcs)
#137 - 5/16"
Nyloc Nut (2pcs)
#149 - 5/16" x 23mm
Flat Washer (2pcs)
ASSEMBLY PACK CHECK LIST
Step 2
#126 - M6 x 10mm
Phillips Head Screw (4pcs)

Xterra FS5.25e Specifications

General

Brand	Xterra
Model	FS5.25e
Category	Elliptical Trainer
Language	English
