Xterra SB120 User Manual

SB120 Recumbent Bike
13
Attaching the Lower Seat
5
1. Lift up the Adjustable Bar (No. 08) and insert the Backrest Support Bracket
(No.3) into the Main Frame (No.1) as shown in the diagram above. Ensure
that the Adjustable Bar (No. 08) is pointing upright when inserting for proper
assembly.
2. Attach the Limited Bracket (No. 27) onto the Main Frame (No. 01) and tighten
with 1 Crossed Head Self-Tapping Screw (No. 22).
22 1 pc M4 x 10L
27 1 pc
73 Allen key
03
27
01
22
03
08
03
08
Yes
No
