AutoProPAD Basic Key Programmer
5
2. Layout of AutoProPAD Basic Tablet
① ② ③
①Micro USB: Battery charge or data synchronization with PC
②DB15 Port: Supports wired connection with car by the cable
③Power Button: Power on or power off
3. AutoProPAD Basic Technical Parameters
Operating System: Android
Processor: Quad-core 1.6GHz Processor
Memory: 1G RAM, 16G FLASH
Display: 7.0 inch touch screen with 1024×600 resolution
Sensors: Gravity sensor, Ambient light sensor
Auto Input/Output: Microphone, dual speakers, 4-band 3.5mm stereo/standard headset jack
Power and Battery: 4000mAh, 3.7V lithium-polymer battery
Power Voltage: 5V
Power Consumption: 8W
Operating Temperature: -20 to 50℃(-4 to 126℉)
Humidity: <90%
Dimension (L*W*H): 218×150×29mm
