3.1.2 Compact (VN) Remote Display Module
The VLC-505 model has the option of being connected to a Remote Display Module mounted into a
Mounting Unit or a 19" Subrack. Unlike the VLP and the VLS detectors, the display module cannot
be mounted into the VLC.
Legend
A Threshold indicators
B Bar graph
C Numerical Display
D Alarm Level LEDs
E Fault LEDs
F Push Button Keys
Figure 3-2: VRT-J00 Display Module mounted into a remote unit

Xtralis VESDA VLC Specifications

General

Brand	Xtralis
Model	VESDA VLC
Category	Smoke Alarm
Language	English
