VESDA by Xtralis VESDA VLC Product Guide
www.xtralis.com 13
3.4 Product Configuration
Legend
A Reset / Isolate Button
B LED Indicators
Figure 3-4: Front view of the VLC detector
Legend
A Programming socket
15 Pin for VLC-505
9PinforVLC-500
B Termination card
C VESDAnet number
D Air filter cartridge
E Filter screw
F Air exhaust port
G Aspirator
H 1.6 Amp fuse
I Anti tamper screw
J Cable entry ports
K Air inlet port
L Wire terminal strips
Figure 3-5: View of components in the enclosures box
