XVision X4D1H User Manual

15
X4D1H – User Manual
Item
Description
Enable
Select checkbox to enable advanced settings
User Name
Enter username (provided by the ISP)
Password
Enter password (provided by the ISP)
IP Address
Enter the fixed IP address (provided by the ISP)
Please Note: This feature may not work with all 3G cards (Please contact technical
support for further details)
1-6.2 HTTP Setup
Item
Description
Enable HTTP
Server
Check to enable HTTP server. Users can remotely access into the
DVR over the network if the HTTP function is activated.
Port
Enter a valid port value from 1 up to 65000 (The default value is 80)
Auto
Assign each channel with its maximum fps
No.
Selected channel number
Quality
Setup the recording quality from the options: Basic, Normal, High,
and highest
FPS
Setup the recording FPS

XVision X4D1H Specifications

General

Brand	XVision
Model	X4D1H
Category	DVR
Language	English
