The number of seconds the alarm buzzer remains activated once
motion has been detected
Select chosen channel to apply the motion detection
Select checkbox to Enable/Disable motion detection for each channel
Drag the on–screen white bar or press ◀ ▶ to set up the motion
detection sensitivity from value 0 to 10 for each channel (i.e. the
higher value the greater the sensitivity)
Select to setup motion detection area
Please Note: 4 camera DVR will display 4 channel options and 8 camera DVR will display
8 channel options.
1-2.1.1 MOTION AREA SETUP
The motion detection has been divided into 22x18 grids. The default detection area is a full
screen. This area is transparent for local access and purple for remote access users.
(i.e. areas deselected from motion detection are marked in red for both local and remote access
users).
