Aquavar IPC Start-Up Genie
CentriPro
INTRODUCTION
The proprietary Start-Up Genie guides you through quick and easy commissioning. Take advantage of
the complete Genie with 11 sections to congure applications with pump protections, I/O options, and
communications. For the more straightforward applications set your motor information and operation mode
and “Autoset” the rest of the parameters. With support for the most common control congurations, the Genie
reduces set-up and conguration time to less than 15 minutes.
The Intelligent Pump Controller (IPC) Start-Up Genie allows the end-user to quickly and easily congure the
controller for pump control applications including single pump, constant slave, duplex control, speed control,
and test run mode. The Genie guides users through the 11 sections for controller conguration. The Setup
Selection screen allows the user to congure the motor, application type, inputs, outputs, pump protection
features, ow compensation, and communications.
Table 1: Setup Selection
SETUP SELECTION
1. Motor
2. Application
3. Feedback
Autoset*
4. Setpoint
5. Flow Compensation
6. Pump Protection Setup
7. Digital Input
8. Relay and Analog Output Setup
9. Communication
10. Copy to LCP
11. Copy from LCP
*At this point, the Autoset conguration window will give users the option to set the remaining parameters to the most common settings.
See Table 2.
Convenience and Simplicity
The Start-Up Genie allows complete system programming in a guided step by step format, leading users to all of
the necessary parameters for operation without manually scrolling through a complex parameter list. The simple
menu and selection screens allow for easy access to the most important sections, utilizing the navigation arrows
and the [OK] button. Several parameter sets are able to be automatically congured to the most common control
congurations, further simplifying controller set up.
While above mentioned auto preset options provide effortless conguration, the Genie provides a single
location for complete customization of parameters allowing users to tailor their controller to the specic
application intended if the autoset congurations are not suitable.
