PAGE 5
Aquavar IPC Start-Up Genie
CentriPro
CHAPTER 2: APPLICATION
Allows the user to congure varying operating modes, units, and ramps. Changing operating modes will
overwrite drive or motor size independent parameters.
OPERATING MODE:
2.1. Single Pump (default): 1 pump/1 controller for constant pressure, level
control, or ow control applications
• APPLICATION TYPE:
• Constant Pressure: Pressure control using a pressure transducer or other
external feedback device with analog signal
• Flow Control: Flow control using a ow meter or other external feedback
device with analog signal
• Level Control: Level control using a level transducer or other external
feedback device with analog signal
• CONTROL UNITS: Select the appropriate control units for the application
(psi, GPM, ft., etc.).
• RAMP TIME: The Ramp Time is the time to transition from stop to full speed.
• Fast = 5s accelerate and 3s decelerate.
