Xylem Flygt 3201 - Product Denomination

1 2 3
4
5
6 7
8
9 10
12
11
13
14
15
1. Approval
2. Approval authority + approval number
3. Approval for Class I
4. Approved drive unit
5. Stall time
6. Starting current/Rated current
7. Duty class
8. Duty factor
9. Input power
10. Rated speed
11. Controller
12. Additional information
13. Maximum ambient temperature
14. Serial number
15. ATEX marking
Figure 2: EN approval plate
EN approval for cable entry:
• Certificate number: INERIS 02ATEX9008 U
•
II 2 G or IM2 EEx d IIC or EEx dI
FM
This illustration describes the approval plate for Factory Mutual (FM) and the information
contained in its fields.
1
2
1. Temperature class
2. Maximum ambient temperature
Figure 3: FM approval plate
Product denomination
Product Description
Flygt 3201 Installation, Operation, and Maintenance Manual 15
