Stator connection Lead color
V5 Brown
W1 Yellow
W2 Black
W5 Yellow
SUBCAB 7GX, 6 stator leads, D connection
This table shows the connection diagrams for the SUBCAB 7GX (3-phase power cables),
with D connection.
D connection
U2W2 V2
V1U1 W1
T1
T2
L1 L2 L3 T1 T2
1 4 2 5 3 6
1 4 2 53 6
T1 T2
T1
T2
T1 T2
W2 U1 V1 U2 W1
V2
SUBCAB
®
SUBCAB
®
SUBCAB 7GX, 6 stator leads, Y/D connection
This table shows the connection diagrams for the SUBCAB 7GX (3-phase power cables),
with Y/D connection.
Installation
Flygt 3201 Installation, Operation, and Maintenance Manual 25
