33
Technical Information
Camera
Image resolution: 1 megapixel (1280 x 720), HD 720p
Field of view (Diagonal): 100
o
Focal length: 2.78
Night vision: High Power IR, up to 8m illumination
Maximum frame rate: 15 FPS
Audio: Built-in microphone
Infrared LEDs: Yes
Operating temperature: 0 - 40
o
c
Interfaces
Bluetooth: BT 4.1 - Bluetooth Low Energy (BLE)
Ethernet: No
Wi-Fi: IEEE 802.11 b/g/n
Frequency: 2.412 - 2.462 GHz
Dimensions & Weight
Camera only (W x H x D): 52.2 x 52.2 x 28mm, 49g
Camera & stand (W x H x D): 52.2 x 70.4 x 57.3mm, 95.8g
Power
Power requirements: 5V / 2A, Micro USB
LED Status Light
Camera
Booting up:
BLUE
Camera
connecting to
Bluetooth and
Wi-Fi:
Blinking BLUE
Camera
connected to
Y-cam servers:
GREEN
Camera
recording:
Blinking
GREEN
Camera
disconnected
from Y-cam
servers or
Wi-Fi:
Blinking RED
Please note the infrared night vision LED is separate to the status
LED. Both LED are both next to each other but should not be
confused.
