Parts List

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

MAIN Unit

FT-7900R/E Technical Supplement

C 1353 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g3

C 1354 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e4

C 1355 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e4

C 1356 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4

C 1358 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4

C 1359 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BZ01D K22178294 1- B e4

C 1361 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e3

C 1362 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e3

C 1363 CHIP TA.CAP. 22uF 16V TEESVB21C226M8R K78120028 1- B d3

C 1364 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f4

C 1365 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B e4

C 1366 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- A D4

C 1367 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B f4

C 1368 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BZ01D K22178291 AUS 1- A D4

C 1368 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BZ01D K22178291 EXP 1- A D4

C 1369 CHIP CAP. 0.47uF 25V B GRM21BB11E474KC01L K22140824 1- B e4

C 1370 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 1- B e4

C 1371 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e4

C 1373 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BZ01D K22178295 1- A D4

C 1374 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- A D4

C 1375 CHIP CAP. 68pF 50V CH GRM1552C1H680JZ01D K22178232 1- A D4

C 1376 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 1- A D4

C 1377 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D3

C 1378 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A D3

C 1379 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D3

C 1380 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4

C 1381 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E4

C 1382 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e4

C 1383 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B e4

C 1384 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f2

C 1385 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 1386 CHIP CAP. 1uF 25V B GRM21BB31E105KA98L K22140826 1- A B4

C 1387 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 1- A C4

C 1388 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C4

C 1389 CHIP CAP. 1uF 25V B GRM21BB31E105KA98L K22140826 1- A C4

C 1390 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A C3

C 1391 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A D3

C 1392 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C3

C 1393 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A C3

C 1394 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- A C2

C 1395 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f3

C 1396 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f3

C 1397 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f2

C 1398 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- A C3

C 1399 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A C3

C 1400 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A C3

C 1401 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A C3

C 1403 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 1- A C2

C 1404 FILM CAP. 47pF 500V UC232H0470J-T K33279034 1- A C2

C 1405 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A D2

C 1406 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f2

C 1407 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B f2

C 1408 FILM CAP. 47pF 500V UC232H0470J-T K33279034 1- A D2

C 1410 FILM CAP. 47pF 500V UC232H0470J-T K33279034 1- A D1

C 1411 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G2

C 1412 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A G2

C 1413 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- A C2

C 1414 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 A1 1- A C2

C 1414 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 A2 1- A C2

C 1414 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 A3 1- A C2

C 1414 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 B1 1- A C2

C 1414 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 B2 1- A C2

C 1414 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 B3 1- A C2

C 1414 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 C1 1- A C2

C 1414 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 C2 1- A C2

C 1414 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 C3 1- A C2

C 1414 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 D1 1- A C2

C 1414 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 D2 1- A C2

C 1414 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 H1 1- A C2

C 1414 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 H2 1- A C2
