Yaesu FT-7900R/E - PANEL Unit Parts List

G-3
Parts List
PANEL Unit
FT-7900R/E Technical Supplement
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
PCB with Components CB2349011 USA
CB2349012 EXP
CB2349013 CE
CB2349014 AUS
Printed Circit Board AH016M000 FR0111800 1-
C 2001 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B a1
C 2002 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B a1
C 2003 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B a1
C 2004 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B a1
C 2005 CHIP CAP. 0.015uF 16V B GRM155B11C153KA01D K22128807 1- B b1
C 2006 CHIP CAP. 0.015uF 16V B GRM155B11C153KA01D K22128807 1- B a1
C 2007 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B h3
C 2008 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B h2
C 2010 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B h1
C 2011 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B h1
C 2013 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B e1
C 2014 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B e2
C 2015 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 2016 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B d2
C 2017 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d2
C 2018 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- B c2
C 2019 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 2020 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B g2
C 2021 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2
C 2022 CHIP CAP. 39pF 50V CH GRM1552C1H390JZ01D K22178226 1- B f2
C 2023 CHIP CAP. 39pF 50V CH GRM1552C1H390JZ01D K22178226 1- B f2
C 2024 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 2025 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c2
C 2026 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 2027 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d2
C 2028 CHIP CAP. 680pF 50V B GRM155B11H681KA01D K22178807 1- B d2
C 2029 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B d2
C 2030 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B d2
C 2031 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B e2
C 2032 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2
C 2033 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d2
C 2034 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B d2
C 2035 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 2036 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2
C 2037 CHIP CAP. 470pF 50V B GRM155B11H471KA01D K22178805 1- B b2
C 2038 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B b2
C 2039 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B b2
C 2040 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b2
C 2041 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B b3
C 2042 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- B b2
C 2043 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2
C 2044 CHIP CAP. 0.0056uF 25V B GRM155B11E562KA01D K22148802 1- B b3
C 2047 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2
C 2050 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g1
C 2051 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g1
C 2052 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e3
C 2053 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 W/ CE 1- A H1
D 2001 LED MA10-1104Q7NC-WK G2070878 1- A G1
D 2002 LED MA10-1104Q7NC-WK G2070878 1- A G2
D 2003 LED 19-213/S2C-AN1P2B/3T G2071096 1- A G1
D 2004 LED 19-213/S2C-AN1P2B/3T G2071096 1- A B1
D 2005 LED 19-213/S2C-AN1P2B/3T G2071096 1- A E2
D 2006 LED 19-213/S2C-AN1P2B/3T G2071096 1- A D2
D 2007 LED 19-213/S2C-AN1P2B/3T G2071096 1- A G2
D 2008 LED 19-213/S2C-AN1P2B/3T G2071096 1- A C2
D 2009 LED 19-213/S2C-AN1P2B/3T G2071096 1- A G2
D 2010 LED 19-213/S2C-AN1P2B/3T G2071096 1- A B2
D 2011 DIODE HZM27WA TR-E G2070530 1- B f3
D 2012 DIODE UDZS TE-17 6.8B G2070888 1- B a1
D 2013 DIODE UDZS TE-17 6.8B G2070888 1- B g1
D 2014 DIODE HZM27WA TR-E G2070530 1- B b1
D 2015 LED 19-213/S2C-AN1P2B/3T G2071096 1- A F2
D 2016 LED 19-213/S2C-AN1P2B/3T G2071096 1- A D2
DS2001 LCD 070520 G6090155 1- A E1
L 2001 M.RFC 1uH LK1608 1R0K-T L1690687 1- B e2
