Yaesu FT-7900R/E - MAIN Unit Parts List

F-9
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
MAIN Unit
FT-7900R/E Technical Supplement
PCB with Components CS1803017 USA
CS1803018 EXP A1
CS1803019 EXP A2
CS1803020 EXP A3
CS1803021 CE B1
CS1803022 CE B2
CS1803023 EXP B3
CS1803024 CE C1
CS1803025 CE C2
CS1803026 EXP C3
CS1803027 EXP D1
CS1803028 EXP D2
CS1803029 AUS H1
CS1803030 AUS H2
Printed Circiit Board AH016M000 FR011170D 1-
FR011170E 116-
C 1001 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BZ01D K22178291 1- B c3
C 1002 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B c4
C 1004 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1006 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1007 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1008 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1009 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c5
C 1010 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c5
C 1011 CHIP CAP. 68pF 50V CH GRM1552C1H680JZ01D K22178232 1- B c4
C 1012 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 1- B c4
C 1013 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B c5
C 1014 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BZ01D K22178285 1- B c5
C 1015 CHIP CAP. 0.75pF 50V CK GRM1554C1HR75BZ01D K22178286 1- B c5
C 1016 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 1- B d5
C 1017 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B d5
C 1018 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BZ01D K22178285 1- B d5
C 1019 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B d5
C 1021 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B d5
C 1022 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d4
C 1023 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BZ01D K22178291 1- A E4
C 1024 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F5
C 1025 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BZ01D K22178293 1- A F5
C 1026 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BZ01D K22178288 1- A F5
C 1027 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BZ01D K22178293 1- A F5
C 1028 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- A E5
C 1029 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F5
C 1030 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BZ01D K22178287 1- A E5
C 1031 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d5
C 1032 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 1- B d5
C 1033 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d5
C 1034 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d5
C 1035 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d5
C 1036 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B b3
C 1037 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B b3
C 1038 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B b3
C 1039 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BZ01D K22178294 1- B b3
C 1042 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B b3
C 1043 CHIP CAP. 10pF 50V CH GRM1552C1H100BZ01D K22178297 1- B b3
C 1044 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BZ01D K22178291 1- B b4
C 1045 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1046 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BZ01D K22178295 1- B b4
C 1047 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b3
C 1048 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BZ01D K22178293 1- B b4
C 1049 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1050 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c4
C 1051 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1053 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BZ01D K22178295 1- B c5
C 1054 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BZ01D K22178288 1- B c5
C 1055 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c5
C 1056 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 1- B c5
C 1057 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B c5
C 1058 CHIP CAP. 0.75pF 50V CK GRM1554C1HR75BZ01D K22178286 1- B c5
C 1059 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B c5
C 1060 CHIP CAP. 0.75pF 50V CK GRM1554C1HR75BZ01D K22178286 1- B c5
